More info
Description
● The upper and bottom bead breaker discs are controlled by hydraulic force, having strong power to increase the demounting efficiency. The maximum bead breaker force can reach to 1400kg.
● The demounting head can be automatic shift to increase the mounting and demounting efficiency.
● The automatic lifting device with lifting power 80KG which can assist operator to lift up the wheel.
● The main shaft is movable in order to adapt different diameter of rims, always keep alignment with the demounting hook.
● The two shift of the main shaft can be adjusted up and down to increase the demounting rim width.
● Standardly equipped with LCD monitoring system, which shows the tire moving position more intuitively.
● The pump motor has automatic stand-by function after no operation for 3 minutes to save energy.
Data sheet
Data sheet
| Model name | IT618 |
| Motor power | 0.85kw/1.1kw |
| Max wheel diameter | 51”(1300mm) |
| Max wheel width | 13”(330 mm) |
| Clamping range | 10”~30” |
| Air supply | 8-10bar |
| Rotation speed | 6.5/13rpm |
| Bead breaker force | 1400kg |
| Power supply | 110/220/380V, 50/60Hz |
| Net weight / Gross weight | 584/692kg |
| Packing dimension | 1680*1150*2000mm |
